29 Inch Aluminum Electric Bike Frame Lightweight Design With Mid - Drive Motor

Product Categories

ORISUN BICYCLE CO., LTD.

Contact Now

29 Inch Aluminum Electric Bike Frame Lightweight Design With Mid - Drive Motor

Brand Name : OEM

Model Number : I6030

Certification : EN,ISO9001

Place of Origin : China

MOQ : 100 units

Price : Negotiable

Payment Terms : T/T In advance, L/C at Sight

Supply Ability : 20000 units/month

Delivery Time : 60 days

Packaging Details : Carton

Product : 29er Electric Mountain Bike Frame

Wheel Size : 27.5er Boost, 29er

Max. Tire : 27.5x3.00 or 29x2.30

Material : Aluminum Alloy 6061, T4& T6 heat treatment

Motor : Shimano Steps E8000 Mid Drive System

Dropout : 148x 12mm thru-axle

Riding Style : XC, Trail/ All Mountain

Sizes : All Popular Sizes

Contact Now

29er Aluminum Electric Bike Frame w/ Shimano E8000 Mid Drive 27.5 Boost Mtb Ebike

Description:

Brushless Mid-Drive Motor generates bigger torque and it has been used as motive of bicycle. Bosch, Shimano, Brose, Panasonic etc all keep on developping such mid-drive system.

I6030 is designed with Shimano interface to support E8000 mid-drive motor. Its wider dropout 148x12 mm fits 29erx 3.0 or 27.5erx2.80 tire,which means more stable when crossing trails and mountains. 500w motor has good power for climbing slopes and hills.

Features:

1) Kinesis Patented Design with Open mold for OEM model. We can OEM for customer's logo and decal.

Kinesis Patented Technology with SPF super plastic forming, TIG+Smooth and Robot-man welding.

2) Lightweight design with spf super plastic forming tubes, thinner tube thickness with bigger intensivity.
2) I6030 fits with Shimano steps E8000 mid-drive motor.
3) Its Dropout 148x12 allows 27.5 boost Wheel size 29erx2.30 or 27.5x 2.80 tire maximum.
4) 69.5 degree headtube angle fit front fork 120-140mm travel.

Technical Data:


Product	29er Electric Bike Frame, 27.5er Boost mtb ebike
Material	Aluminum Alloy 6061, T4 &T6 heat treatment
Motor	Shimano E8000 Mid-Drive Motor
Model	I6030
Rear Dropout	148 x 12 thru-axle
Wheel Size	27.5er Boost, 29er
Max tire	29er x2.30 or 27.5er x 3.00
Size available	All Popular Sizes
Headtube	Tapered (44/56mm)
Heat tube angle	69.5 degree
Fork Length	530 mm
Reach	408.5mm (18")
Stack	605mm (18")
RC	440 mm(18")
Seatpost	31.6 mm
Brake	Disc (Post Mount, Hidden)
Routing	Internal Cable Routing
Riding Style	XC,Trail, All Mountain
OEM/ODM	acceptable
Welding	TIG+SMT+robotman welding
Design	Kinesis Patented
Mold	Open Mold
Sample order	Acceptable
Painting & Logo	As per customer's requirement
Features	Lightweight with SPF technology.
